Wide Angle Windows 1080 Hd Webcam Micro Usb For 4k Camera Android Microphone Stand Accessory Pc Accessories

Price : $400.00 - $600.00/Pieces Packaging Details : Every Unit in Color box with PE Foam;<br>Strong carton for transportation.
Supply Ability : 5000 Piece/Pieces per Month
Place of Origin: Guangdong, China Brand Name: Oneking/OEM
Model Number: T1L-AM

Detail Information

Type: Network Conference System, Video Conference System Function: Other
Simultaneous Interpretation: NO Image Flip: Support
CPU: Cortex-A17 Quad-Core1.8GHz Keyword: Android Video Conference
Effective Pixel: 2.1MP Focus: F=4.7mm-47mm
Communication Protocol: VISCA, PELCO-D, UVC1.5 HOV: 54°
Zoom: 10x Optical Preset Position: 64
Product Name: Usb For 4k Camera Android Microphone Stand Accessory Pc Accessories Port: Shenzhen

Product Description

Wide Angle Windows 1080 Hd Webcam Micro Usb For 4k Camera Android Microphone Stand Accessory Pc Accessories

Wide Angle Windows 1080 Hd Webcam Micro Usb For 4k Camera Android Microphone Stand Accessory Pc Accessories

Wide Angle Windows 1080 Hd Webcam Micro Usb For 4k Camera Android Microphone Stand Accessory Pc Accessories 0





Android Conferencing Codec
1) Cortex-A17 Quad core
Mali-T764, 3D GPU
2GB DDRIII 16GB(EMMC) 10x PTZ
2) USB2.0*2 OTG*1 HD*1
3) 1/2.9" SONY CMOS, 2.1 Megapixel
4) 10x optical Zoom, f=4.7mm-47mm, HOV 54°




 Wide Angle Windows 1080 Hd Webcam Micro Usb For 4k Camera Android Microphone Stand Accessory Pc Accessories 2Wide Angle Windows 1080 Hd Webcam Micro Usb For 4k Camera Android Microphone Stand Accessory Pc Accessories 4Wide Angle Windows 1080 Hd Webcam Micro Usb For 4k Camera Android Microphone Stand Accessory Pc Accessories 6Wide Angle Windows 1080 Hd Webcam Micro Usb For 4k Camera Android Microphone Stand Accessory Pc Accessories 8Wide Angle Windows 1080 Hd Webcam Micro Usb For 4k Camera Android Microphone Stand Accessory Pc Accessories 10Wide Angle Windows 1080 Hd Webcam Micro Usb For 4k Camera Android Microphone Stand Accessory Pc Accessories 12Wide Angle Windows 1080 Hd Webcam Micro Usb For 4k Camera Android Microphone Stand Accessory Pc Accessories 14

Specification



PC Hardware Specification

CPU

Cortex-A17 Quad-Core1.8GHz

GPU

Quad-Core Mali-T764, 3D GPU

RAM

DDRIII 2G

SSD

16GB (EMMC)

Internet

2.4GHz/5GHz WiFi 802.11 b/g/n & 802.11 ac. (Wifi module optional)

LAN 10M/100M/1000M

Bluetooth

Support BT4.0 Module (Optional)

Audio Input

3.5mm MIC IN (Optional)

Audio Output

SPK OUT 3.5mm(Optional)/HD Audio Out

Peripheral Interface

USB2.0*2,  OTG*1,  HD *1

TF*1

RJ45*1

OS

Android 5.1

PTZ Camera Specification

Sensor

1/2.9" SONY CMOS

Effective Pixel

2.1 Megapixel

Min Illumination

0.1Lux at F1.6

White Balance

Auto/Manual/Indoor/Outdoor/ATW

Gain Control

Auto

Back Light Compensation

On/Off

Electronic Shutter

1/60-1/10,000S

SN Ratio

>50db

Focus

f=4.7mm-47mm

Iris

F1.6-F2.5

Zoom

10x Optical

HOV

54°

Video Output Format

MJPEG: 1080P30/25, 720P30/25,  640*480, 640*360

Baud Rate

9600bps/38400bps

Communication Interface

USB

Communication Protocol

VISCA/PELCO-D/UVC1.5

Speed Match

Support

OSD Menu

Support

Image Flip

Support

Pan Movement Speed

1-60°/S

Tilt Movement Speed

1-60°/S

Pan Movement

0-355°

Tilt Movement

90°(UP),30°(DOWN)

Preset Position

64

Power Input

100V-240V 1.5A AC 50-60HZ

Power Output

DC12V 2A

Work Temperature

0-50 ℃

Work Humidity

0-90% RH

Dimension

284mm*147mm*161mm


(Conference Camera

)

Related Products

Wide Angle Windows 1080 Hd Webcam Micro Usb For 4k Camera Android Microphone Stand Accessory Pc Accessories 16

FAQ

Why choose us:

1. We provide OEM&ODM service with strong R&D development,

2. Free main board replacement for any faulty products within 1-2 years warranty.Low Repair Rate is our best reward during past 13 years.

3.100% inspection before shipping.



Q:What kind of camera should I use?

A:For meeting room spaces, we have video conferencing cameras and Omnidirectional microphones that are specifically designed for small huddle rooms, conference and boardrooms,and large auditorium spaces.You can check our service guide for more information on different meeting room systems.


Q:Is it easy to operation?
A:Yes, it is easy to install, plug and play.

Q:What is the resolution of your cameras?
A:We have 1920x1080p/60fps progressively output, and 1080p/30fps also 720p/30fps.

Q:What is the Video Connector?
A:There are USB 2.0, USB3.0,HMI,HD-SDI,DVI,YPBPR and CVBS Video output.

Q:How many time zoom?
A:Support fixed focus, 3X , 10X, 12X, 20X, 30X optical zoom.

Q:How to control this Camera?
A:There are RS232, RS485 PTZ Control, and also support VISCA, PELCO-D to control through your Codec or PC through RS232, and support IR remote control.

Q:Which kind of software

A:Compatible with all Popular Web Conferencing System
