Hawkvine VC033 Educational Intelligent Auto Tracking Camera 12X 20X Digital Zoom HD CMOS sensor
Hawkvine VC033 Educational Intelligent Auto Tracking Camera 12X 20X Digital Zoom HD CMOS sensor Hawkvine VC033 Educational Intelligent Auto Tracking Camera 12X 20X Digital Zoom HD CMOS sensor Hawkvine VC033 Educational Intelligent Auto Tracking Camera 12X 20X Digital Zoom HD CMOS sensor Hawkvine VC033 Educational Intelligent Auto Tracking Camera 12X 20X Digital Zoom HD CMOS sensor
Contact Now

Hawkvine VC033 Educational Intelligent Auto Tracking Camera 12X 20X Digital Zoom HD CMOS sensor

Minimum Order Quantity : 1PCS Price : 100-10000
Packaging Details : Carton Packing Delivery Time : 15days
Payment Terms : L/C, T/T Supply Ability : 1000 Per month
Place of Origin: CHINA Brand Name: Hawkvine
Certification: TS16949 Model Number: VC033

Detail Information
Hawkvine No.: HV-VC033 Image Sensor: 1/2.8 Inch High Quality HD CMOS Sensor
Digital Zoom: 10X Video Interface: 3G-SDI

Product Description

Hawkvine VC033 Educational Intelligent Auto Tracking Camera 12X 20X Digital Zoom HD CMOS sensor.

Hawkvine VC033 Educational Intelligent Auto Tracking Camera 12X 20X Digital Zoom HD CMOS sensor 0Hawkvine VC033 Educational Intelligent Auto Tracking Camera 12X 20X Digital Zoom HD CMOS sensor 1

VC033 KEY FEATURES


1.Superb High-definition Image
VC033 employs 1/2.8 inch high quality CMOS sensor. Resolution is up to 1920×1080 with frame rate up to 60 fps.


2.Low Noise and High SNR
Low Noise CMOS effectively ensure high SNR of camera video.Advanced 2D/3D noise reduction technology is used to further reduce the noise, while ensuring image sharpness.


3.Multiple Video Compression
Support H.264/H.264+ video compression. Support compression of resolution up to 1920×1080 with frame up to 60 fps and 2 channels 1920x1080p with 30 fps compression.



4.Wide-range, Quiet and Quick Pan/Tilt Mechanism
By adopting step driving motor mechanism, VC033 camera works extremely quiet and moves smoothly without any noises.


5.Multiple Network Protocol
Support ONVIF,RTSP,RTMP protocols and support RTMP push mode.


6.Low-power Sleep Function
Support low-power sleep/wake up, the consumption is lower than 400mW under sleep mode.


7.Audio Input Interface
Support 16000,32000,44100,48000 sampling frequency and AAC,MP3,PCM audio coding.



Parameters/Model VC033-12X VC033-20X
Tracking Camera and Lens Parameter
Sensor 1/2.8 inch high quality HD CMOS sensor
Effective Pixels 2.07 megapixel; 16:9
Video Signals 1080P60/50/30/25/59.94/29.97 ,1080I60/50/59.94,720P60/50/30/25 / 59.94 /2 9.97
Optical Zoom 12x optical zoom f＝3.9～46.1mm 20x optical zoom f＝4.7～94mm
View Angle 6.3°(tele)～72.5°(wide) 2.9°(tele)～55.4°(wide)
Iris F1.8 ～ F2.4 F1.6 ～ F3.5
Digital Zoom X10
Minimum Illumination 0.5Lux(F1.8, AGC ON)
Digital Noise Reduction 2D﹠3D digital noise reduction
White Balance Manual/Auto/One Push/ 3000K/ 4000K/5000K/6500K
Focus Auto/Manual
Aperture Auto/Manual
Electronic Shutter Auto/Manual
BLC ON/OFF
WDR OFF/Dynamic Range adjustment
Video Adjustment Brightness,Color,Saturation,Contrast,Sharpness,Gamma curve
SNR >55dB
Panoramic Camera
Sensor 1/3 inch high quality HD CMOS sensor
Effective Pixels 2.1 megapixel
Lens Manual Focus
View Angle(D/H/V) 122°/98°/73°
Input/Output Interface and Protocols
Video Interface 3G-SDI
Network Interface 100M network interface (10/100BASE-TX) 5G WiFi(optional), Support VISCA protocol control through IP port
Network Protocol RTSP,RTMP,ONVIF,GB/T28181
Compress Image Code Stream Dual stream output
Video Compress Format H.264,H.265
Control Signal Interface RS-232
Control Protocol VISCA/Pelco-D/Pelco-P Baud Rate:115200/9600/4800/2400bps
Audio Input Interface Dual audio channel 3.5mm linear input
Audio Compress Format AAC,MP3,PCM
Power Interface HEC3800 power jacket(DC12V)
Pan Tilt Parameter
Pan Rotation -170°～+170°
Tilt Rotation -30°～+90°
Pan Control Speed 0.1 ～100°/s
Tilt Control Speed 0.1～45°/s
Preset Speed Pan: 100°/s,Tilt:45°/s
Preset Number User can set up to 255 presets(remoter 10 presets)
Other Parameters
Supply Adapter Input AC110V-AC220V to DC12V/2.5A
Input Voltage Output DC12V±10% POE power supply optional
Input Current 1.5A(Max.)
Consumption 18W(Max.)
Store Temperature -10℃～+60℃
Store Humidity 20%～95%
Working Temperature -10℃～+50℃
Working Humidity 20%～80%
Dimension(WxHxW) 254mmX144mmX174mm
Weight(appr.) 1.54kg
Application Indoor
Remote Maintenance (LAN) Remote Update,Remote Reboot,Remote Reset
Accessory 12V/2.5A power supply adapter,RS232 control cable,Remote Controller,User Manual,Warranty Card,brackets(optional)
